1214RE

4D34i

100kW (140 hp) @ 2500 rpm

420 Nm @ 1500-2000 rpm

4 Nos, 3907 cc

BSIV

G85 - 6F+1R, Mechanical, Synchromesh gears

Single dry plate, Hydraulic control with clutch booster, 362mm

IF 4.5, Reverse elliot

DANA S145, Fully floating, Hypoid gears

6.33, 6.33, 5.13, 5.13

12,800 kg

Channel section with cross member

228mm x 80mm x 6mm

Semi elliptic leaf spring with hydraulic shock absorbers

Semi elliptic laminated leaf spring

Optional (Front & Rear)

Pneumatic, Foot operated, Dual line with ABS

Pneumatically operated spring brake

6.50 x 20, 8.25 x 20 – 16PR (crossply) & 6.50 x 20 , 8.25 R 20 – 16PR (radial optional)

Hydraulic power assisted

Day Cabin, Tiltable (A/C optional)

200 litres

27 litres

24V Electrical system

2 x 12 V, 75 Ah

27.5% / 21.5%

80 km/hr

14.8 m, 14.8 m, 16.7 m, 18.7 m

Cabin with Chassis

Fixed Side Deck, High Side Deck, Drop Side Deck

Comfort Pack (HVAC)
